II Equipment performance description and characteristic
1.     Applicable lid diameterφ30~φ100mm，Lid thickness 8~60mm，Bottle diameter (diagonal) 40-130mm，Bottle height 80-350mm(out of the size need to customized)；
2.     Suitable for hard round lids with obvious deviations in the center of gravity of the lid. The hopper capacity is 225 liters. About 300-500 lids can be poured at one time；
3.     Adjustable production efficiency, up to 45 cans per minute；
4.     The overall appearance is mainly made of stainless steel 304, thickness 1.2mm；
5.     Plexiglass material uses imported acrylic, thickness 8-10mm, high-end atmosphere；
6.     The capping heads is embedded with PP glue, which has wide applicability and will not damage the cover.；
7.     Adopt PLC intelligent program design and touch screen control, easy to use and set；
8.     Servo motor capping, capping torque and speed adjustment can be easily set and controlled；
9.     Capping alarm function with missing cover alarm to ensure efficient and uninterrupted work of the equipment；
10.   Adjustable downtime without cover to ensure efficient and uninterrupted work of the equipment and effectively      reduce equipment failures；
11.   Change bottle diameter need to change mould, the mould including turntable,capping heads, drop lid groove,Depending on the actual situation, the upper cover conveyor belt may be replaced. It takes about 50-60 minutes
12.   Same diameter in different height, it just need to adjust, but if the height in big different, it maybe change turntable, according to bottle size.
13.   For different lid, you can change different hanging and pressing methods, such as the vibrating plate feeding cover buckle and turntable type capping, etc.；
14.   Configuration conveyor length 3.78 meters, height 0.9 meters, chain width 114mm；
15.   Equipment size L3.78m*W1.1m*H2.15m，Packaging wooden size ： Press machine size L1.25m*W0.95m*H1.76m, capping machine size L1.55m*W1.10m*H1.89m, Lid elevator machine size L2.30m×W0.71m×H1.46m；
16.   Net weight is about
