II Equipment performance description and characteristics
1.Weighing range：20-2000g（related to reference material）
2.Weighing accuracy：±1-3g（accuracy is related to material）
3.Weighing speed：15-25cans/min(according to filling material and capacity)
4.Large hopper capacity: 40L, combined weigher single hopper capacity: 3L
5.Drive mode: stepper motor
6.Operation interface: 7-inch touch screen
7.Applicable can diameterφ40~φ130mm，height 50~200mm（customized according to can size）
8.Different can diameter that need to change filling head, and it need about 10 minute to adjust change it；
9.In different height can, it do not need to change any mould, it just need to take about 5 minute to adjust it；
10.The overall appearance material is mainly made of stainless steel 304, and the thickness of the chassis is about 1.5mm；
11.Conveyor belt motor power 0.2KW, four bucket weighing power 0.8kw, total 1kw, single-phase 220V voltage；
12.Air source configuration: about 2 cubic meters per minute, 0.6-0.8Mpa, air source or air pump as auxiliary equipment needs to be prepared by yourself；
13.The size of the equipment is L2000*W1000*H2000mm, the height of the conveyor belt from the ground is 900mm, and the width of the chain is 114mm (the size can be customized if required)；
14.The packing size of the weighing head: L1100*W1050*H1050mm, the net weight is about 200KG, the gross weight is about 350KG, the packing size of the receiving part: 2050*950*1500mm, the net weight is about 150KG, the gross weight is about 250KG；
15.The configuration can be selected according to the actual situation: Teflon plate / pattern plate / 10 inch touch screen / vibration device；
16.Range of use: suitable for quantitative weighing of granular sugar, salt, rice, beans, seeds, condiments, washing powder, feed, desiccant, plastic pellets, hardware, etc., can also be used with packaging machines, and can be fully automated Filling
