| ITEM | UNIT | DATA | ||||
| Injection Unit | Screw Diameter | mm | 40 | 45 | 48 | |
| Screw L/D Ratio | L/D | 22.5 | 20.3 | 19 | ||
| Injection Volume | cm3 | 251 | 318 | 362 | ||
| Shot Weight | g | 229 | 289 | 329 | ||
| Injection Pressure | Mpa | 202 | 159 | 140 | ||
| Clamping Unit | Clamping Force | KN | 1680 | |||
| Opening Stroke | mm | 420 | ||||
| Mould Thickness(Min-Max) | mm | 180-500 | ||||
| Space Between Tie-Bars | mm | 455×455 | ||||
| Ejector Force | KN | 45 | ||||
| Ejector Stroke | mm | 140 | ||||
| General | Motor Power | KW | 15 | |||
| Heater | KW | 10 | ||||
| Pump Pressure | Mpa | 16 | ||||
| Machine Dimension | m | 5.2×1.3×2.1 | ||||
| Machine Weight | T | 4.8 | ||||
| Mould Orientation Ring Diameter | mm | 125 | ||||
| Nozzle Radius | mm | SR15 | ||||
